TMiO Web Interface

TMiO Duo Web Interface

In doing this you will lose connection to TPS and will need to reconnect the Trackman to TPS afterwards

1. Method 1: Accessing The Web Interface via Trackman Performance Studio
   1. Open Trackman Performance Studio
   2. Connect your Trackman unit to Trackman Performance Studio as normal
   3. Click on Settings in the bottom right corner of TPS
   4. Then Click on Advanced in the top right corner of TPS
   5. From here click on the About tab on the left hand side of the screen
   6. Then click on Show Device Web Interface
   7. Click Login

1. Method 2: Accessing The Web Interface via Ethernet
   1. Be sure radar is connected to PC via Ethernet
   2. Open File Explorer on the computer
   3. Click "Network" on the left hand side of the File Explorer window
   4. If there is a yellow bar at the top that says Network Discovery is turned off, click on the bar and turn on Network Discovery
   5. Once Network Discovery is turned on, you should see the radar followed by its serial number
   6. Right click the radar device
   7. Click "Properties"
   8. Here you should see a web link that you can click on, this will take you to the web interface
   9. Click Login
