Steps on How to Calibrate a Trackman iO

1. Open the Calibration Screen
   • Launch TPS and open the Calibration screen.
   • Please note that the projector needs to be turned on through the calibration process.
2. Position the Calibration Board on the Screen
   • Hold the TMiO calibration board high up against the top of the hitting screen.
   • The camera on the TMiO will automatically calculate the distance to the screen.
3. Click "Calibrate"
   • Once the board is in place, click the Calibrate button.
4. Place the Board on the Ground
   • Move the calibration board to the ground, facing the hitting screen.
   • Align the purple cross on the board with the white cross shown on screen.
   • Try to get them as perfectly aligned as possible.
5. Confirm Alignment
   • Click Continue, then click Continue again.
6. Auto Target Setup
   • The unit will now perform an Auto Target to establish the correct target line.
   • Once it completes, click Continue one last time.
7. Dynamic Sim Option
   • Decide whether to keep Dynamic Sim enabled or disable it using the checkbox on this screen.
   • This setting affects how the simulator adjusts visuals based on shot data.
