Step 1: Plan Out Frequencies

1. Determine Frequencies:
   • Frequencies range from -5 to +5.
   • Plan the frequency for each bay, ensuring that adjacent bays have frequencies as far apart as possible.

Step 2: Access the Advanced Settings

1. Open TPS (Trackman Performance Studio):
   • Launch the TPS software on your computer.
2. Navigate to Settings:
   • Click the three lines at the bottom right of the screen.
   • Select Settings from the menu.
   • In the Settings menu, click on Advanced Settings at the top right corner.
3. Access Device Web Interface:
   • Scroll down to the bottom left corner and select About.
   • Click Show Device Web Interface.

Step 3: Configure Manual AFS

1. Log In to the Web Interface:
   • When prompted, select Login without entering any credentials (leave the field blank).
2. Set Up Manual AFS:
   • In the web interface, navigate to Setup on the left-hand side.
   • Click on Advanced.
   • Under the AFS section, choose Manual.
   • Enter the planned frequencies for both options as per your frequency plan.
   • Click Apply to save your settings.

Step 4: Repeat for Other Bays

1. Repeat the Process:
   • Follow the same steps to configure Manual AFS for each bay in your facility.
   • Ensure each bay's frequency aligns with your plan to avoid overlap and interference.
